丁基膠涂布機常見問題的解決方法： 1.鋁框上出現一邊或兩邊都不沾膠的現象時我們應檢查膠缸、膠頭的溫度是否正常，壓力是否在我們設定的范圍之內，檢查兩膠頭的距離是否過大（此距離設定至鋁條剛剛能從兩個打膠頭之間過去為好）。

　　Solution to common problems with butyl rubber coating machine: 1. When there is no glue on one or both sides of the aluminum frame, we should check whether the temperature of the glue cylinder and glue head is normal, whether the pressure is within the range we set, and whether the distance between the two glue heads is too large (this distance should be set until the aluminum strip can just pass between the two glue heads).

　　如果上述情況都沒有問題，可斷定兩個打膠頭（或一個），由于丁基膠中有雜質而堵住了膠頭出膠的眼，這就需要卸下打膠頭，用煤油浸泡，然后將膠頭內的膠全部清理干凈后再裝上即可。

　　If the above situations are not a problem, it can be concluded that two or one of the glue heads have blocked the glue outlet due to impurities in the butyl rubber. This requires removing the glue head, soaking it in kerosene, and then cleaning all the glue inside the glue head before reinstalling it.

　　2.該設備全部采用液壓系統，油缸及液壓系統全部采用高壓油管連接，每個連接處都由組合墊密封，若發現漏油，及時更換組合墊。

　　2. The equipment adopts a hydraulic system, and the oil cylinder and hydraulic system are all connected by high-pressure oil pipes. Each connection is sealed with a combination gasket. If oil leakage is found, the combination gasket should be replaced in a timely manner.

　　3.該設備的膠頭加熱和膠缸加熱，由加熱棒兩個和加熱盤一個提供，由溫控表來設定和調整溫度的高低，若發現溫度升不高或升高后往下降，請檢查加熱棒或加熱盤是否損壞，并檢查溫控表是否正常

　　3. The heating of the rubber head and the heating of the rubber cylinder of the device are provided by two heating rods and one heating plate. The temperature is set and adjusted by a temperature control meter. If the temperature does not rise or rises and then falls, please check whether the heating rod or heating plate is damaged and whether the temperature control meter is normal

　　新型免卸壓，手動調節膠嘴距離丁基膠涂布機

　　New type of pressure free, manually adjustable nozzle distance butyl rubber coating machine

　　中空玻璃鋁條丁基膠涂布機免泄壓力免松螺絲，直接調整膠嘴間隙免泄壓丁基膠涂布機，免泄壓丁基膠打膠機，中空鋁隔條丁基膠機設備，中空玻璃鋁條丁基膠涂布機免泄壓力免松螺絲，直接調整膠嘴間隙省去了繁瑣的膠頭調整間隙的時間，避免了操作不熟練所產生的漏膠等故障問題。

　　Hollow glass aluminum strip butyl rubber coating machine without pressure relief or loosening screws, directly adjusting the gap between the rubber nozzle without pressure relief butyl rubber coating machine, non pressure relief butyl rubber gluing machine, hollow aluminum spacer butyl rubber machine equipment, hollow glass aluminum strip butyl rubber coating machine without pressure relief or loosening screws, directly adjusting the gap between the rubber nozzle saves the time of adjusting the gap of the rubber head, avoiding problems such as glue leakage caused by unskilled operation.

　　免泄壓丁基膠涂布機是現在的中空玻璃設備當中先進的打膠設備，還有就是雙組份打膠機是打密封膠的，也是先進的，具備純氣動，可推拉帶萬向輪的。

　　The pressure relief free butyl rubber coating machine is an advanced gluing equipment among the current insulated glass equipment. The two-component gluing machine is also advanced for gluing sealant, with pure pneumatic and push-pull universal wheels.

　　該機有plc機控制，人機界面操作，自動準確完成涂膠動作，并有多速段調節，生產效率高。

　　This machine is controlled by a PLC machine, operated by a human-machine interface, automatically and accurately completes the gluing action, and has multi speed adjustment, resulting in high production efficiency.

　　采用不銹鋼工作臺面，并加裝定位裝置，該機適用于仿形，長方形，圓形各種不同規格的鋁間隔框。

　　The machine adopts a stainless steel worktable and is equipped with a positioning device. It is suitable for aluminum spacer frames of various specifications, including imitation, rectangular, and circular.

　　耐高溫密封設計，解決了涂布機普遍存在的漏膠難題。

　　High temperature resistant sealing design solves the common problem of glue leakage in coating machines.

　　該機分液壓系統和氣液系統增壓工作。

　　The machine is divided into hydraulic system and gas-liquid system for boosting work.

　　此款丁基膠涂布機省去了之前泄壓力的麻煩，操作簡單，實用方便。

　　This butyl rubber coating machine eliminates the trouble of pressure relief before, with simple operation and practical convenience.

　　丁基膠涂布機(丁基膠涂膠機)是在鋁間隔框兩側均勻涂丁基膠的專用設備, 操作人員只需手扶鋁間隔框, 其它動作均由設定程序自動完成,

　　The butyl rubber coating machine (butyl rubber coating machine) is a specialized equipment that evenly applies butyl rubber on both sides of the aluminum spacer frame. The operator only needs to hold the aluminum spacer frame with their hand, and other actions are automatically completed by the set program,

　　丁基膠涂布機(丁基膠涂膠機)采用人機界面, 操作方便, 涂膠效果好, 生產效率高, 是中空玻璃生產中必不可少的設備.

　　The butyl rubber coating machine adopts a human-machine interface, which is easy to operate, has good coating effect, and high production efficiency. It is an essential equipment in the production of insulating glass

　　【丁基膠涂布機(丁基膠打膠機)技術參數】

　　Technical parameters of butyl rubber coating machine (butyl rubber gluing machine)

　　工作氣壓：0.5-0.8MPa

　　Working pressure: 0.5-0.8MPa

　　輸入電源：380V / 220V

　　Input power supply: 380V/220V

　　50HZ

　　50HZ

　　輸入功率：4.2KW

　　Input power: 4.2KW

　　輸出速度：14m/min

　　Output speed: 14m/min

　　打膠溫度：110℃-150℃

　　Glue temperature: 110 ℃ -150 ℃

　　擠膠壓力：12-15MPa

　　Squeezing pressure: 12-15MPa

　　膠頭可調范圍：14-23mm

　　Adjustable range of adhesive head: 14-23mm

　　外形尺寸：3000×700×1200mm

　　Dimensions: 3000 × 700 × 1200mm

　　重量（約）：800Kg

　　Weight (approximately): 800Kg

　　新型免卸壓丁基膠涂布機_丁基膠打膠機_中空玻璃打膠_臥式丁基膠涂布機

　　New type of pressure free butyl rubber coating machine, butyl rubber gluing machine, hollow glass gluing machine, horizontal butyl rubber coating machine
